Inline Pump, Vertical Pump, Direct Coupling Pump, Pipeline Pump, Vertical Single Stage Pump
Vertical hot water pumps are suitable for high-temperature hot water pressurized circulation and transportation in metallurgy, chemical industry, textile, wood processing, papermaking, as well as boilers, bathrooms, hotels and other industries, and for urban housing heating circulation pumps, with operating temperatures below 120 ℃.
Vertical high-temperature centrifugal pumps are widely used in energy, metallurgy, chemical, textile, papermaking, as well as boiler high-temperature hot water pressurized circulation transportation in hotels, bathrooms, and guesthouses, and pipeline pumps for urban housing heating circulation, with operating temperatures below 240 ℃.
Vertical pipeline chemical pump is used to transport liquids that do not contain solid particles, are corrosive, and have a viscosity similar to water. It is suitable for industries such as petroleum, chemical, metallurgical, power, papermaking, food and pharmaceuticals, and synthetic fibers. The operating temperature ranges from -20 ℃ to 120 ℃.
Description
Pipeline pump is also named inline pump and is a single suction single-stage vertical structure (also known as booster pump) because its inlet and outlet are on the same straight line and have the same diameter, resembling a section of pipeline, and can be installed at any position in the pipeline. Structural features: It is a single suction single-stage centrifugal pump with the same inlet and outlet on the same straight line, perpendicular to the axis centerline, and is a vertical pump.
Parameters
Capacity: 6.3-1600 m3/h
Lift Head: 5-150 m
Rotary Speed: 980, 1480, 2950 r/min
Calibre: Φ 15 to Φ 500
Temperature: 0 to +120degrees
Working Pressure: ≤ 1.6 Mpa
Liquid temperature between -10℃ and +120℃
Ambient temperature up to +50℃
Max. working pressure 16 bar
Application
1. Send the fresh water
2. Suitable for industry and city's giving and draining off water
3. It is convenient to form a complete set with other apparatus
4. High efficiency, low noise
5. There are cold water types, hot water type, high temperature type, chemical industry type, oil type
6. Performance is reliable
Suitable for use with clean water and liquids that are not chemically aggressive towards the materials from which the pump is made.
The EN733 centrifugal pumps are recommended for use in water supply, cleaning sets, pressure boosting, firefighting sets, irrigation, industrial applications, water circulation in climatisation sets, agricultural.
Competitive Advantage
We can make it for energy saving type. Highly efficiency and Energy saving, with tube-type structure, easy for installation, Electro-mechanically integrated design, Space efficient,
Easy for service just by disassembling the nut of the pump bonnet and taking out the motor and the actuator unit. Wide application scope.
The struction is unique: the pump can be pull out from common base of the motor pump unit directly, which will be convenient for maintenance.
