Vertical Axial Mixed Flow Pump
Extra large horizontal and inclined axial flow pump, suitable for pumping clean water, sewage, rainwater, and slightly corrosive liquids, with the conveyed liquid temperature not exceeding 50 ℃. This type of pump is a high flow, low head pump that can be used for agricultural irrigation, water conservancy engineering, urban water supply, drainage, and sewage treatment. It can also be used for transporting circulating water in power plants, salt factories, and breeding farms, and for raising and lowering water levels in shipyards. It can also be used in industries such as metallurgy and chemical engineering, and is widely used.
Description
Feature of vertical Axial flow pump
● Optimized elbow passage of better hydraulic performance.
● Adjustable impeller of high efficiency and wide high efficiency zone.
● Slowly pump speed design conforms to the technological requirements of salting out and low temperature crystallization.
● Vertical axial flow pumps are widely used in saltworks, obtaining salt by evaporating brine, composite alkali process, etc. Selecting corrosion-resistant materials and high-strength shafts to ensure smooth operation and long service life of vertical axial flow pumps. The diameter of suction bowl of the vertical axial flow pump is from 225mm to 3100mm, so it has a wide range of applications.
● Specially designed to suit different applications. With the help of our professional engineers, special design could be carried out to increase the head, increase the guide vane body, and realize the function of a vertical mixed-flow pump; Wear resistant coating is added to the impeller for the medium containing corrosive and hard particles, so that the service life of the vertical pump is greatly extended. Increasing the system pressure and liquid level can achieve the purpose of forced circulation.
Parameters
| Capacity: | Q=250~55000(m³/h) |
| Head: | H=1.5~8 (m) |
| Speed: | n=180~1450rpm |
| Fluid s.g.: | γ ≤1.5 |
| Fluid temperature: | T=0~180ºC |
| Fluid viscosity: | ν ≤600(mm2/s) |
| Pump diameter: | Ф250mm~1800mm |
Application
Applications of Vertical Axial Flow Pumps
Vertical axial flow pumps are suitable for applications of big flow with low total head.
● Agricultural drainage and irrigation;
● Water supply and drainage of power station;
● Urban flood prevention;
● Urban water supply;
● Water supply and drainage of docks;
● Thermoelectricity station circulating water transferring;
● Dock water level rising and lowering;
● Aquaculture;
● Saltworks draw water;
● Salting out and low temperature crystallization of combined soda process;
● Phosphoric acid, obtaining salt by evaporating seawater and other chemical industries.
Competitive Advantage
All items of vertical turbine pump manufactured from our company are made by investment casting, finish cast die, precise casting mould. Our items range a wide area.
