This series of products has a wide spectrum, good hydraulic performance and novel structure. It is characterized by high efficiency, good cavitation performance, easy installation and maintenance, at the same time , combined with the latest information control technology, the intelligent water pump system independently developed can be configured, with automatic monitoring function.

1: The use of this type of submersible electric pump is the most thorough way to solve the problem of motor flood control in areas along rivers and lakes with large water level fluctuations. It also eliminates the need for long shafts and intermediate bearings between the pumps, making the operation of the unit more reliable and greatly improving efficiency. Submersible axial flow pump: The electric motor driving the water pump is a dry fully enclosed submersible three-phase asynchronous motor, which can operate in water for a long time and has a series of unparalleled advantages over traditional units.

2: Due to the integration of the motor and water pump, there is no need for labor-intensive and time-consuming assembly processes for the motor, transmission mechanism, and water pump axis alignment at the installation site, making on-site installation convenient and fast.

3: Due to its submerged operation, the civil engineering of the pump station can be greatly simplified, the installation area can be reduced, and the project cost can be saved by 30-40%.

4: Low noise, no high temperature inside the pump station, improving the operating environment. A fully underground pump station can be built as required to maintain the surface environment.

● By reason that the pump can run in water, it is helpful for simplifying the earth work and building engineering of pumping station.

● For integration of water pump and motor, it is unwanted to perform axis-to-center assembly procedure on site, very convenient and expeditions to install.

● Low noise, no high temperature brought in the pumping station, it is available in building full underground pumping station according to requirements to keep the ground environment.

● Convenience in operation, it is not necessary to lubricate the rubber bearing of bump prior to turning on the machine, in addition, remote control and auto control are realized.

● Can solve the flood resistance problem of the river and with lake with fluctuation of water level.

● This type submersible axial-flow pump is suitable for the occasion of low head and large flow, and this type submersible mixed-flow pump is of high efficiency and perfect cavitation performance, suitable for the occasions of large fluctuation of water level and high head. The transmission medium is the water of other liquid similar to the water on physical and chemical property, the max temperature of transmitted liquid is 40℃.

Submersible axial pump with adjust able impellers has the advantages of large capacity, broad head, high efficiency, wide application. It mainly for water supply in cities, diversion works, sewage drainage system, sewage disposal project, flood control.

● Application Fields

● Industry & agriculture

● Water supply for cities

● Mild sewage drainage

● Environmental protection

● Water transfer project

The large flow submersible axial flow pump manufactured by our company is a necessary equipment specially used for flood discharge of Rivers and Lakes and reservoirs. This type of water pump has a super large flow rate and can autonomously discharge water when the water level reaches its peak, striving to eliminate water disasters in the first place. The flow rate of submersible axial flow pumps can reach tens of thousands of cubic meters. In order to meet various usage requirements, in addition to conventional wellbore installation, we have also introduced horizontal floating installation, inclined sled installation and other methods. On the basis of ensuring the normal use function and efficiency of the water pump, the installation becomes simpler.
